Technical Specifications of Vigor3300V
|
| Hardware Interface |
LAN |
4 x 10/100M Base-TX LAN switch, RJ-45 |
| WAN/DMZ |
4 x 10/100M Base-TX WAN/DMZ switch, RJ-45 |
| VoIP |
2 x slots for FXS/FXO/ISDN S0, TE/ISDN all TE |
| Console Port |
1 x console , RJ-45 |
| Reset |
1 x factory reset button |
| VoIP |
Protocol : SIPv2 (RFC-3261), MGCP, RTP/RTCP |
| Multiple SIP proxies registrars |
| Jitter buffer (125ms) |
| G.168 line each-cancellation |
| Automatic gain control |
| Packet loss concealment |
| Outbound proxy |
| FXO-PIN code |
| NAT traversal (STUN, RFC-3489) |
| Voice codes: G.711 A/? laws, G.723.1, G.726, G.729 A/B, VAD/CNG |
| Tone generation and detection : DTMF, dial, busy, ring back, call progress |
| DTMF Tone : Out band (RFC-2833),SIP info |
| FAX/Modem support |
Tone detection |
| G.711 pass-through |
| T.38 FAX relay, T.30 transparent |
| Modem support rate up V.92 (G.711 only) |
| Supplemental services |
Internal call |
| Call hold/retrieve |
| Call waiting |
| Call waiting with caller ID |
| Call transfer |
| Call forwarding (always, busy, answer) |
| Call barring (incomin?g/outgoing) |
| DND (do note disturb) |
| Hotline |
| Incoming call barring |
| FXS incoming/outgoing preset number |
| Feature phone * |
| Dial Plan |
Phone book |
| Digit map |
| Call barring |
| Regional |
| Caller ID Support :Bellcore,ETSI, NTT, DTMF-based (nor-europe) |
| ISDN |
ISDN failover (Loop through [available on 2 TE/NT (S0) interface module] |
| ISDN On-Net/Off-Net |
| 10 MSN on each ISDN S0 port for VoIP call |
| Signaling compliance : ITU-T Rec. Q920, Q921, Q930, Q931 |
| Multi WAN |
Outbound policy based load balance |
Allow you local network to access Internet using multiple Internet connections with high-level of Inter?net connectivity availability |
| 4 dedicated Ethernet WAN ports (10/100Mb/s) |
| WAN failover or load balanced connectivity |
| Redundancy |
| By PC clients |
| By WAN interface traffic volume |
| By destination IP address range |
| By fixed VPN connection |
| By fixed VoIP packets |
| Robust detection mechanism |
| IP aliasing |
| Auto-detect line status |
| Bandwidth on demand |
| WAN Protocol |
Ethernet : PPPoE, PPTP, DHCP Client, Static IP, L2TP, BPA |
| ISDN : DSS1 (Euro ISDN), PPP, ML-PPP(64/128Kbps) |
| VPN |
Protocols : PPTP, IPSec, L2TP, L2TP over IPSec |
| Up to 200 sessions simultaneously |
| VPN Trunking |
| PFS (DH Group) |
| Prevent Replay Attack |
| VPN throughput |
| NAT-traversal (NAT-T) |
| PKI Certificate |
| IKE authentication |
| Authentication |
| Encryption |
| RADIUS Client |
| DHCP over IPSec |
| Dead Peer Detection (DPD) |
| Smart VPN software utility |
| Easy of adoption |
| Industrial-standard interoperability |
| Firmware |
Stateful Packet Inspection (SPI) |
| Multi-NAT |
| Port redirection |
| Open ports |
| DMZ host |
| Policy-based IP packet filter |
| DoS/DDoS prevention |
| IP address anti-spoofing |
| Object-based firewall |
| Notification |
| Bind IP to MAC address |
| WDS security |
| Content filter |
URL keyword blocking |
| Web content filter |
| Time schedule control |
| Bandwidth management |
Traffic shaping |
| Bandwidth reservation |
| DiffServ codepoint classifying |
| 4 priority levels (inbound/outbound) |
| Individual IP bandwidth/session limitation |
| Bandwidth borrowing |
| user-defined class-based rules |
| System management |
Web-based user interface (HTTP) |
| DrayTek's Quick Start Wizard |
| User administration |
| CLI (Command Line Interface,Telnet/SSH) |
| DHCP client/relay/server |
| Dynamic DNS |
| Administration access control |
| Configuration backup/restore |
| Built-in diagnostic function |
| NTP client.call scheduling |
| Tag-based VLAN (802.1Q) |
| Firmware upgrade via TFTP/HTTP |
| Remote maintenance |
| Logging via syslog |
| SNMP management |
SNMP v2 |
| MIB II |
| Routing function |
Router |
| Advanced routing and forwarding |
| DNS |
| DHCP |
| NTP |
| Policy-based routing |
| Dynamic routing |
| Static routing |
| Working with VigorCSM |
Basic Configuration |
| Performance monitoring |
| Topology |
| Security |
| Log |
| Alarm |
| Polling |
| VPN/firewall configuration |
| VoIP configuration |
| Alarm for VPN/firewall |
| Support |
2-year limited warranty |
| Free firmware upgrade from Internet |
| Declaration of Conformity |
|
 |
| Max. Power |
52 Watt |
| Dimension |
L443 * W297 * H44 (mm) |
| Power |
90 ~ 260 VAC |
